OpenShift Join New Node to Cluster

bySystem Engineer -
0

 Configure Node

This is assuming that the box is already imaged










  1. Create affinity rules for new nodes



  2. Become root

    sudo su -

  3. RUN THESE COMMAND IF YOU HAVE SPACE IN THE LOGICAL VOLUME (Go to #4 otherwise)
    Extend 80GB to /var/ and 10G to /var/log/

    lvextend -L +10G /dev/vg1/lv_var_log
    xfs_growfs /dev/vg1/lv_var_log
    lvextend -L +80G /dev/vg1/lv_var
    xfs_growfs /dev/vg1/lv_var

  4. Add a 80GB HDD (Thick Provision Eager Zeroed) to the VM and extend 70GB to /var/ and 10G to /var/log/



    #Run the command below if disk doesn't show up in lsblk
    for x in 0 1 2; do echo "- - -" > /sys/class/scsi_host/host${x}/scan; done
    find /sys/class/scsi_device/ -mindepth 1 -maxdepth 1 | while read f; do echo 1 > "${f}/device/rescan"; done
    #Change the name if necessary
    parted /dev/sdb

    #run the below in (parted)
    mklabel gpt
    mkpart primary 2048s -1
    quit

    #Extend share
    pvcreate /dev/sdb1 && vgextend vg1 /dev/sdb1 && lvextend -L +10G /dev/vg1/lv_var_log && xfs_growfs /dev/vg1/lv_var_log && lvextend -l +100%FREE /dev/vg1/lv_var && xfs_growfs /dev/vg1/lv_var

  5. Permit Root login without password and add Bootstrap node SSH to allowed key list

    sed -i 's/PermitRootLogin.*/PermitRootLogin without-password/g' /etc/ssh/sshd_config
    systemctl restart sshd
    mkdir .ssh && chmod 700 .ssh && touch .ssh/authorized_keys && chmod 600 .ssh/authorized_keys
    echo <serverAbcs1 ssh_key> > .ssh/authorized_keys

  6. Run YUM update to prevent docker headaches later on

    yum update -y

  7. Rest of the configuration

    #install python library
    yum install -y pyOpenSSL python-rhsm-certificates jq python-configparser rng-tools python2-passlib

    #remove immutable flag so docker can use this
    chattr -i /etc/resolv.conf

    #OpenShift plays with DNS resolution so this is just to prevent long waits when troubleshooting issues
    sed -i 's/^#\(UseDNS\).*$/\1 no/g' /etc/ssh/sshd_config && systemctl restart sshd

    #This was a security lockdown feature, but ends up scanning the docker containers and messing with them, causing them to break
    /bin/rm -f /etc/cron.daily/unowned_files

    #Required for dnsmasq service
    systemctl enable NetworkManager && systemctl start NetworkManager

    #Make sure that running lots of pods doesn't cause us to run out of entropy on the hosts
    systemctl enable rngd && systemctl start rngd

  8. CUDAML Specific: Create NIC bonding

    cat > /etc/sysconfig/network-scripts/ifcfg-bond0 << EOF
    DEVICE=bond0
    TYPE=Bond
    NAME=bond0
    BONDING_MASTER=yes
    BOOTPROTO=none
    ONBOOT="yes"
    IPV6INIT="no"
    NM_CONTROLLED=no
    BONDING_OPTS="mode=4 miimon=100 lacp_rate=1"
    EOF

    egrep IPADDR /etc/sysconfig/network-scripts/ifcfg-em1 >> /etc/sysconfig/network-scripts/ifcfg-bond0
    egrep GATEWAY /etc/sysconfig/network-scripts/ifcfg-em1 >> /etc/sysconfig/network-scripts/ifcfg-bond0
    egrep NETMASK /etc/sysconfig/network-scripts/ifcfg-em1 >> /etc/sysconfig/network-scripts/ifcfg-bond0
    echo 'ZONE=public' >> /etc/sysconfig/network-scripts/ifcfg-bond0
    cat > /etc/sysconfig/network-scripts/ifcfg-em1 << EOF
    NAME=em1
    DEVICE=em1
    BOOTPROTO=none
    ONBOOT=yes
    NM_CONTROLLED=no
    IPV6INIT=no
    MASTER=bond0
    SLAVE=yes
    EOF

    cat > /etc/sysconfig/network-scripts/ifcfg-em2 << EOF
    NAME=em2
    DEVICE=em2
    BOOTPROTO=none
    ONBOOT=yes
    NM_CONTROLLED=no
    IPV6INIT=no
    MASTER=bond0
    SLAVE=yes
    EOF

    cat > /etc/sysconfig/network-scripts/ifcfg-bond0.160 << EOF
    bond0.160
    DEVICE=bond0.160
    NAME=bond0.160
    BOOTPROTO=none
    IPADDR="10.17.160.148"
    NETMASK="255.255.252.0"
    ONBOOT="yes"
    VLAN=yes
    IPV6INIT="no"
    NM_CONTROLLED=no
    ZONE=public
    EOF

    modprobe --first-time 8021q
    systemctl restart network

Add Node to OpenShift Cluster

  1. SSH to the Openshift Bootstrap server and become root

    ssh serverAbcs01.xyz.domain
    sudo su -

  2. Navigate to the ansible folder and edit the host file

    cd ~/ansible
    vi hosts-3.11

  3. Add the new host FQDN along with the node type under [new_nodes]







  4. Run the scale up Ansible Playbook

    ansible-playbook -i hosts-3.11 ~/openshift-ansible-3.11/playbooks/openshift-node/scaleup.yml

  5. SSH to a Master node and verify that the nodes were added

    ssh serverAbcm01.xyz.domain
    sudo su -
    oc get nodes

  6. Optional: If the nodes were added, but shows up as "Not Ready", and "oc describe node <node_name" return "Error 'NetworkPluginNotReady message:docker: network plugin is not ready: cni config uninitialized'"

    cat > /etc/origin/node/resolv.conf <<EOF
    nameserver 192.168.20.10
    EOF

    cat > /etc/dnsmasq.d/origin-upstream-dns.conf << EOF
    server=192.168.20.10
    EOF

    #CUDAML BOX ONLY
    cat > /etc/resolv.conf << EOF
    domain xyz.domain
    search cluster.local xyz.domain org11.net
    nameserver <change me -- server IP

  7. Set the new node as unschedulable

    oc adm manage-node <node-name> --schedulable=false

  8. SSH to the node that were created. Downgrade docker (if needed to MATCH the version on the master nodes) on the node and reboot

    Notice

    MATCH the docker version to the Master nodes!

    Previous versions we used have a bug that causes PLEG to become unhealthy and mark pods as unknown:

    docker-1.13.1-91.git07f3374.el7.centos.x86_64

    docker-common-1.13.1-91.git07f3374.el7.centos.x86_64

    docker-client-1.13.1-91.git07f3374.el7.centos.x86_64

    systemctl stop origin-node
    systemctl stop docker
    sudo yum downgrade -y docker-1.13.1-109.gitcccb291.el7.centos.x86_64 docker-common-1.13.1-109.gitcccb291.el7.centos.x86_64 docker-client-1.13.1-109.gitcccb291.el7.centos.x86_64
    sudo reboot

Compute Node Specific Configuration

The steps below are only for OpenShift Compute Node.

  • Perform these steps on the Bootstrap node
  • Run oc login -u duc.le os.org11inc.xyz to login to the cluster
  • Make sure to change the hostnames in these scripts first

  • These scripts should already exists in /root/ansible/shiftn-setup (See serverAbcS01) - Create the directory and add these scripts in other wise

    1-configure-for-cifs.sh Collapse source
    #!/bin/bash
    KUBE_PLUG_DIR="/usr/libexec/kubernetes/kubelet-plugins/volume/exec/fstab~cifs"
    for x in `seq 9 9`; do
      for y in m n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        ssh PUNV-shift${y}0${x} "yum clean all; yum install -y cifs-utils; mkdir -p ${KUBE_PLUG_DIR};";
        cat - << "EOF" | ssh PUNV-shift${y}0${x} "cat > ${KUBE_PLUG_DIR}/cifs"
    #!/bin/bash
    set -u
    # ====================================================================
    # Example configuration:
    # ====================================================================
    # --------------------------------------------------------------------
    # secret.yml:
    # --------------------------------------------------------------------
    # apiVersion: v1
    # kind: Secret
    # metadata:
    #   name: cifs-secret
    #   namespace: default
    # type: fstab/cifs
    # data:
    #   username: 'ZXhhbXBsZQo='
    #   password: 'c2VjcmV0Cg=='
    #   domain: 'ZG9tYWluCg=='
    #
    # --------------------------------------------------------------------
    # pod.yml:
    # --------------------------------------------------------------------
    # apiVersion: v1
    # kind: Pod
    # metadata:
    #   name: busybox
    #   namespace: default
    # spec:
    #   containers:
    #   - name: busybox
    #     image: busybox
    #     command:
    #       - sleep
    #       - "3600"
    #     imagePullPolicy: IfNotPresent
    #     volumeMounts:
    #     - name: test
    #       mountPath: /data
    #   volumes:
    #   - name: test
    #     flexVolume:
    #       driver: "fstab/cifs"
    #       fsType: "cifs"
    #       secretRef:
    #         name: "cifs-secret"
    #       options:
    #         networkPath: "//example-server/backup"
    #         mountOptions: "dir_mode=0755,file_mode=0644,noperm"
    # --------------------------------------------------------------------
    # Uncomment the following lines to see how this plugin is called:
    echo >> /tmp/cifs.log
    date >> /tmp/cifs.log
    echo "$@" >> /tmp/cifs.log
    init() {
      assertBinaryInstalled mount.cifs cifs-utils
      assertBinaryInstalled jq jq
      assertBinaryInstalled mountpoint util-linux
      assertBinaryInstalled base64 coreutils
      echo '{ "status": "Success", "message": "The fstab/cifs flexvolume plugin was initialized successfully", "capabilities": { "attach": false, "selinuxRelabel": false, "fsGroup": false } }'
      exit 0
    }
    assertBinaryInstalled() {
      binary="$1"
      package="$2"
      if ! which "$binary" > /dev/null ; then
        errorExit "Failed to initialize the fstab/cifs flexvolume plugin. $binary command not found. Please install the $package package."
      fi
    }
    errorExit() {
      if [[ $# -ne 1 ]] ; then
        echo '{ "status": "Failure", "message": "Unknown error in the fstab/cifs flexvolume plugin." }'
      else
        jq -Mcn --arg message "$1" '{ "status": "Failure", "message": $message }'
      fi
      exit 1
    }
    doMount() {
      if [[ -z ${1:-} || -z ${2:-} ]] ; then
        errorExit "cifs mount: syntax error. usage: cifs mount <mount dir> <json options>"
      fi
      mountPoint="$1"
      shift
      json=$(printf '%s ' "${@}")
      if ! jq -e . > /dev/null 2>&1 <<< "$json" ; then
        errorExit "cifs mount: syntax error. invalid json: '$json'"
      fi
      networkPath="$(jq --raw-output -e '.networkPath' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: option networkPath missing in flexvolume configuration."
      fi
      mountOptions="$(jq --raw-output -e '.mountOptions' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: option mountOptions missing in flexvolume configuration."
      fi
      fsGroup="$(jq --raw-output -e '.["kubernetes.io/fsGroup"]' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: fsGroup not found."
      fi
      cifsUsernameBase64="$(jq --raw-output -e '.["kubernetes.io/secret/username"]' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: username not found. the flexVolume definition must contain a secretRef to a secret with username, password, and domain."
      fi
      cifsPasswordBase64="$(jq --raw-output -e '.["kubernetes.io/secret/password"]' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: password not found. the flexVolume definition must contain a secretRef to a secret with username, password, and domain."
      fi
      cifsDomainBase64="$(jq --raw-output -e '.["kubernetes.io/secret/domain"]' <<< "$json" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: domain not found. the flexVolume definition must contain a secretRef to a secret with username, password, and domain."
      fi
      cifsUsername="$(base64 --decode <<< "$cifsUsernameBase64" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: username secret is not base64 encoded."
      fi
      cifsPassword="$(base64 --decode <<< "$cifsPasswordBase64" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: password secret is not base64 encoded."
      fi
      cifsDomain="$(base64 --decode <<< "$cifsDomainBase64" 2>/dev/null)"
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: domain secret is not base64 encoded."
      fi
      if ! mkdir -p "$mountPoint" > /dev/null 2>&1 ; then
        errorExit "cifs mount: failed to create mount directory: '$mountPoint'"
      fi
      if [[ $(mountpoint "$mountPoint") = *"is a mountpoint"* ]] ; then
        errorExit "cifs mount: there is already a filesystem mounted under the mount directory: '$mountPoint'"
      fi
      if [[ ! -z $(ls -A "$mountPoint" 2>/dev/null) ]] ; then
        errorExit "cifs mount: mount directory is not an empty directory: '$mountPoint'"
      fi
      result=$(mount -t cifs "$networkPath" "$mountPoint" -o "uid=$fsGroup,gid=$fsGroup,username=$cifsUsername,password=$cifsPassword,domain=$cifsDomain,context=system_u:object_r:container_file_t:s0,$mountOptions" 2>&1)
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs mount: failed to mount the network path: $result"
      fi
      echo '{ "status": "Success" }'
      exit 0
    }
    doUnmount() {
      if [[ -z ${1:-} ]] ; then
        errorExit "cifs unmount: syntax error. usage: cifs unmount <mount dir>"
      fi
      mountPoint="$1"
      if [[ $(mountpoint "$mountPoint") != *"is a mountpoint"* ]] ; then
        errorExit "cifs unmount: no filesystem mounted under directory: '$mountPoint'"
      fi
      result=$(umount "$mountPoint" 2>&1)
      if [[ $? -ne 0 ]] ; then
        errorExit "cifs unmount: failed to unmount the network path: $result"
      fi
      echo '{ "status": "Success" }'
      exit 0
    }
    not_supported() {
      echo '{ "status": "Not supported" }'
      exit 1
    }
    command=${1:-}
    if [[ -n $command ]]; then
      shift
    fi
    case "$command" in
      init)
        init "$@"
        ;;
      mount)
        doMount "$@"
        ;;
      unmount)
        doUnmount "$@"
        ;;
      *)
        not_supported "$@"
        ;;
    esac
    EOF
        ssh PUNV-shift${y}0${x} "chmod 755 ${KUBE_PLUG_DIR}/cifs;";
      done;
    done;
    2-configure-cifs-for-shiftn-only.sh Collapse source
    for x in `seq -w 9 16`; do
      echo "Copying SELinux module definition to server ..."
      cat - << "EOF" | ssh -q serverAbcn${x} "cat > ${HOME}/container_access_cifs.te"
    module container_access_cifs 1.0;
    require {
      type cifs_t;
      type container_t;
      class filesystem mount;
      class file { ioctl read write create getattr setattr lock append unlink link rename open };
      class dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    }
    #============= container_t ==============
    allow container_t cifs_t:filesystem mount;
    allow container_t cifs_t:file { ioctl read write create getattr setattr lock append unlink link rename open };
    allow container_t cifs_t:dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    EOF
      echo "Compiling SELinux module definition ..."
      ssh -q serverAbcn${x} "checkmodule -M -m -o container_access_cifs.mod container_access_cifs.te && semodule_package -o container_access_cifs.pp -m container_access_cifs.mod && semodule -i container_access_cifs.pp;";
    done;
    3-configure-for-trident.sh Collapse source
    #!/bin/bash
    for x in `seq 9 9`; do
      for y in m n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        ssh PUNV-shift${y}0${x} "yum install -y sg3_utils";
        #ssh -t serverAbc${y}${x} "systemctl status iscsi";
        ssh -t PUNV-shift${y}0${x} "systemctl restart iscsi";
      done;
    done;
    4-configure-docker-image-cleanup.sh Collapse source
    #!/bin/bash
    CRON_FILE="/etc/cron.weekly/docker-image-cleanup.sh"
    for x in `seq 9 9`; do
      for y in n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        ssh -q PUNV-shift${y}0${x} "touch ${CRON_FILE}; chmod 755 ${CRON_FILE};";
        cat - << "EOF" | ssh -q PUNV-shift${y}${x} "cat > ${CRON_FILE}"
    #!/bin/sh
    docker image prune -af
    EOF
      done;
    done;
    5-configure-nodes-for-httpd-proxying.sh Collapse source
    #!/bin/bash
    for x in `seq 9 9`; do
      #ssh serverAbcn0${x} "/usr/sbin/getsebool httpd_can_network_connect";
      ssh serverAbcn0${x} "/usr/sbin/setsebool -P httpd_can_network_connect 1";
    done;
    6-configure-docker-registries.sh Collapse source
    #!/bin/bash
    orgA_DIR="/etc/docker/certs.d/orgA-docker.xyz.domain:5000"
    LOCAL_DIR="/etc/docker/certs.d/docker-registry.default.svc:5000"
    for x in `seq 9 9`; do
      for y in m n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        ssh PUNV-shift${y}0${x} "mkdir -p ${orgA_DIR}; mkdir -p ${LOCAL_DIR};";
        ssh PUNV-shift${y}0${x} "ln -sf /etc/pki/ca-trust/source/anchors/hqi1v-opsica01-2017.crt ${orgA_DIR}/;";
        ssh PUNV-shift${y}0${x} "ln -sf /etc/origin/node/client-ca.crt ${LOCAL_DIR}/;";
      done;
    done;
    7-fix-docker-log-rotation.sh Collapse source
    #!/bin/bash
    for x in `seq 14 16`; do
      for y in m n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        ssh PUNV-shift${y}${x} "echo -e '{\n    \"log-driver\": \"json-file\",\n    \"log-opts\": {\"max-size\": \"50m\", \"max-file\": \"3\"}\n}' > /etc/docker/daemon.json; systemctl restart docker;";
      done;
    done;
    8-label-all-nodes-for-filebeat.sh Collapse source
    #!/bin/bash
    for x in `seq 1 8`; do
      for y in m n i; do
        if [ "${x}" -gt "3" ] && [ "${y}" != "n" ]; then continue; fi;
        oc label node PUNV-shift${y}0${x}.xyz.domain logging-infra-filebeat=true;
      done;
    done;
    9-label-compute-nodes-as-normal.sh Collapse source
    #!/bin/bash
    for x in `seq 1 8`; do
      oc label node serverAbcn0${x}.xyz.domain orgA-compute=normal;
    done;
  • SSH to the new node and Reboot it

  • SSH to the Master node and make the new node schedulable

    oc adm manage-node <node_name> --schedulable=true


CUDA Node (Machine Learning) Specific Configuration

The steps below are only for OpenShift CUDA compute node.


  1. SSH to an Openshift master node and add labels + assign node permission to machine learning team

    #Add label
    oc edit node serverxyzl07.xyz.domain -o yaml
      labels:
        ....
        logging-infra-filebeat: "true"
        orgA-compute: gpu
        openshift.com/gpu-accelerator: "true"
        tfserving: "true"

    #Add new cuda node under "resourceNames" so the Machine Learning team can manage it
    oc edit clusterrole machinelearning-view-nodes

  2. SSH to a host with perl installed (or run yum install perl) and run the perl script below

    #Create a perl script to generate iqn for iscsi connection
    vi iqn.pl
    :set paste

    #!/usr/bin/perl
    # Generate a sample IQN for the hostname
    $|=1;
    use strict;
    $ARGV[0] || die "Usage: $0 hostname\n";;
    my $hostname = $ARGV[0];
    #sample: iqn.1994-05.com.redhat:86a2b96edecc
    my @chars = ('0'..'9', 'a'..'f');
    my $len = 12;
    my $string;
    my $hex;
    while($len--){ $hex .= $chars[rand @chars] };
    my ($sec,$min,$hour,$mday,$mon,$year,$wday,$yday,$isdst) = localtime();
    $year+=1900;
    my $iqn = "iqn.$year-$mon.net.org11.$hostname:$hex";
    print $iqn, "\n";

    #Make the script executable
    chmod +x iqn.pl

    #run the script with the node hostname
    ./iqn.pl XYZSERVER

    #this will generate:
    iqn.2020-0.net.org11.XYZSERVER7:39462cf8328b

  3. Go to the Storage Management and add iSCSI connection (We're using v5000 in Vegas, so this is https://lvp0p-v5kmva-mgmt)

     Click here to expand...

  4. Add iSCSI to CUDAML node and enable iSCSI


    groupadd -g 1000460000 -r machinelearning-containers;
    useradd -c "machinelearning container user" -M -r -s /sbin/nologin -u 1000460000 -g 1000460000 machinelearning-containers;

    # Set iSCSI initiator name
    cat > /etc/iscsi/initiatorname.iscsi << EOF
    InitiatorName=iqn.2020-0.net.org11.serverxyzl06:2114872d8665
    EOF

    # Configure CHAP secrets
    vim /etc/iscsi/iscsid.conf

    node.session.auth.authmethod = CHAP
    node.session.auth.username = iqn.2020-0.net.org11.XYZSRVERl07:39462cf8328b
    node.session.auth.password = <CHAP_secret_for_host>
    node.session.auth.password_in = <CHAP_secret_for_cluster>

    discovery.sendtargets.auth.authmethod = CHAP
    discovery.sendtargets.auth.username = iqn.2020-0.net.org11.XYZSERVER:39462cf8328b
    discovery.sendtargets.auth.password = <CHAP_secret_for_host>
    discovery.sendtargets.auth.password_in = <CHAP_secret_for_cluster>

    # Set iSCSI session timeout
    sed -i 's/^\(node.session.err_timeo.abort_timeout =\).*$/\1 60/g' /etc/iscsi/iscsid.conf;

    # Set iSCSI session max commands in queue
    sed -i 's/^\(node.session.cmds_max =\).*$/\1 1024/g' /etc/iscsi/iscsid.conf;

    # Set iSCSI session queue depth
    sed -i 's/^\(node.session.queue_depth =\).*$/\1 128/g' /etc/iscsi/iscsid.conf;

    cat > /etc/udev/rules.d/99-storwize.rules << "EOF"
    ACTION=="add|change", KERNEL=="sd[a-z]", ATTRS{vendor}=="IBM", ATTR{queue/scheduler}="noop", ATTR{queue/add_random}="0", ATTR{queue/rq_affinity}="2", ATTR{queue/nr_requests}="1024", ATTR{queue/max_sectors_kb}="2048", RUN+="/sbin/hdparm -Q 64 /dev/%k", RUN+="/bin/sh -c 'echo 60 > /sys/$DEVPATH/device/timeout'"
    EOF

    udevadm control --reload
    udevadm trigger

    #Scan for iSCSI target in Vegas v5k
    iscsiadm -m discovery -t sendtargets -p 10.17.160.31:3260
    iscsiadm -m discovery -t sendtargets -p 10.17.160.32:3260
    iscsiadm -m discovery -t sendtargets -p 10.17.160.33:3260
    iscsiadm -m discovery -t sendtargets -p 10.17.160.34:3260

    #Add iSCSI node
    iscsiadm -m node --portal 10.17.160.31:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node2 -l
    iscsiadm -m node --portal 10.17.160.33:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node2 -l
    iscsiadm -m node --portal 10.17.160.32:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node1 -l
    iscsiadm -m node --portal 10.17.160.34:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node1 -l

    #Set iSCSI startup to automatically connect to these node
    iscsiadm -m node --portal 10.17.160.31:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node2 -o update -n node.startup -v automatic
    iscsiadm -m node --portal 10.17.160.33:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node2 -o update -n node.startup -v automatic
    iscsiadm -m node --portal 10.17.160.32:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node1 -o update -n node.startup -v automatic
    iscsiadm -m node --portal 10.17.160.34:3260 --target iqn.1986-03.com.ibm:2145.lvp0p-v5kmva.node1 -o update -n node.startup -v automatic

    iscsiadm -m node

    systemctl restart multipathd
    systemctl status multipathd

  5. Add NVIDIA Yum Repo and install NVIDIA packages

    cat > /etc/yum.repos.d/nvidia.repo << "EOF"
    [cuda]
    name=Official Nvidia CUDA YUM Repo
    gpgcheck=1
    gpgkey=http://hqi1v-opspxe01.xyz.domain/public/nvidia/7/cuda/x86_64/7fa2af80.pub
    baseurl=http://hqi1v-opspxe01.xyz.domain/public/nvidia/7/cuda/x86_64/latest
    [libnvidia-container]
    name=libnvidia-container
    gpgcheck=1
    gpgkey=http://hqi1v-opspxe01.xyz.domain/public/libnvidia-container/7/x86_64/gpgkey
    baseurl=http://hqi1v-opspxe01.xyz.domain/public/libnvidia-container/7/x86_64/latest
    [nvidia-container-runtime]
    name=nvidia-container-runtime
    gpgcheck=1
    gpgkey=http://hqi1v-opspxe01.xyz.domain/public/nvidia-container-runtime/7/x86_64/gpgkey
    baseurl=http://hqi1v-opspxe01.xyz.domain/public/nvidia-container-runtime/7/x86_64/latest
    EOF

    yum -y install kernel-devel-`uname -r`
    yum -y install nvidia-driver nvidia-driver-devel nvidia-driver-cuda nvidia-modprobe
    yum -y install nvidia-container-runtime-hook --nogpgcheck

  6. Remove default NVIDIA driver and add the NVIDIA yum-installed package driver. Verify by setting up docker container that works with this driver

    #Remove default driver
    modprobe -r nouveau

    #Add NVIDIA driver
    nvidia-modprobe && nvidia-modprobe -u

    #Setup container using docker to test NVIDIA driver
    docker run --privileged -it --rm docker.io/mirrorgooglecontainers/cuda-vector-add:v0.1

    #Remove this image once the previous command produce a SUCCESS
    docker rmi docker.io/mirrorgooglecontainers/cuda-vector-add:v0.1

  7. Setup SELINUX context so that any arbitrary user in docker container can use the CUDA library

    #Change security context for this folder
    chcon -t container_file_t /dev/nvidia*;

    #Download this selinux post processed file
    curl -LO https://raw.githubusercontent.com/zvonkok/origin-ci-gpu/master/selinux/nvidia-container.pp

    #Add to our SELINUX context
    semodule -i nvidia-container.pp

    #Reset SELINUX to the updated context
    nvidia-container-cli -k list | restorecon -v -f -
    restorecon -Rv /dev
    restorecon -Rv /var/lib/kubelet

    #Test using docker image again
    docker run --user 1000:1000 --security-opt=no-new-privileges --cap-drop=ALL   --security-opt label=type:nvidia_container_t   -it --rm docker.io/mirrorgooglecontainers/cuda-vector-add:v0.1

    #Remove once the previous command produce a SUCCESS
    docker rmi docker.io/mirrorgooglecontainers/cuda-vector-add:v0.1

  8. Setup SELINUX context so OpenShift can R/W CIFS in CUDA Docker container and reboot after finished

    cat > container_mount_cifs.te << "EOF"
    module container_mount_cifs 1.0;
    require {
      type cifs_t;
      type container_t;
      class filesystem mount;
    }
    allow container_t cifs_t:filesystem mount;
    EOF

    checkmodule -M -m -o container_mount_cifs.mod container_mount_cifs.te;
    semodule_package -o container_mount_cifs.pp -m container_mount_cifs.mod;
    semodule -i container_mount_cifs.pp;
    semanage fcontext --add --type container_file_t   "/var/lib/origin/openshift.local.volumes/pods/[^/]+/volumes/fstab~cifs(/.*)?"

    cat > container_access_cifs.te << "EOF"
    module container_access_cifs 1.0;
    require {
      type cifs_t;
      type container_t;
      class filesystem mount;
      class file { ioctl read write create getattr setattr lock append unlink link rename open };
      class dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    }

    allow container_t cifs_t:filesystem mount;
    allow container_t cifs_t:file { ioctl read write create getattr setattr lock append unlink link rename open };
    allow container_t cifs_t:dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    EOF

    checkmodule -M -m -o container_access_cifs.mod container_access_cifs.te;
    semodule_package -o container_access_cifs.pp -m container_access_cifs.mod;
    semodule -i container_access_cifs.pp;

    cat > nvidia_container_access_cifs.te << "EOF"
    module nvidia_container_access_cifs 1.0;
    require {
      type cifs_t;
      type nvidia_container_t;
      class filesystem mount;
      class file { ioctl read write create getattr setattr lock append unlink link rename open };
      class dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    }
    allow nvidia_container_t cifs_t:filesystem mount;
    allow nvidia_container_t cifs_t:file { ioctl read write create getattr setattr lock append unlink link rename open };
    allow nvidia_container_t cifs_t:dir { ioctl read write create getattr setattr lock unlink link rename add_name remove_name reparent search rmdir open };
    EOF

    checkmodule -M -m -o nvidia_container_access_cifs.mod nvidia_container_access_cifs.te;
    semodule_package -o nvidia_container_access_cifs.pp -m nvidia_container_access_cifs.mod;
    semodule -i nvidia_container_access_cifs.pp;

    #Test
    docker run --user 1000:1000 --security-opt=no-new-privileges --cap-drop=ALL   --security-opt label=type:nvidia_container_t   -it --rm docker.io/mirrorgooglecontainers/cuda-vector-add:v0.1

    semanage fcontext --add --type container_file_t --ftype c "/dev/nvidia.*"
    sed -i 's/ -Z / --context=system_u:object_r:container_file_t:s0 /g' /usr/lib/udev/rules.d/60-nvidia-uvm.rules
    cat >> /etc/rc.local << "EOFEOF"
    /sbin/modprobe nvidia-uvm
    if [ "$?" -eq 0 ]; then
      D=`grep nvidia-uvm /proc/devices | awk '{print $1}'`
      mknod -m 666 --context=system_u:object_r:container_file_t:s0 /dev/nvidia-uvm c $D 0
      mknod -m 666 --context=system_u:object_r:container_file_t:s0 /dev/nvidia-uvm-tools c $D 1
    else
      exit 1
    fi
    EOFEOF

    reboot

  9. Add new cudaml entry to all cudaml nodes /etc/hosts file

    [root@XYZ~]# cat /etc/hosts
    127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
    ::1         localhost localhost.localdomain localhost6 localhost6.localdomain6

    10.17.148.141 serverxyzl01.xyz.domain
    10.17.148.142 serverxyzl02.xyz.domain
    10.17.148.143 serverxyzl03.xyz.domain
    10.17.148.144 serverxyzl04.xyz.domain
    10.17.148.146 serverxyzl05.xyz.domain
    10.17.148.147 serverxyzl06.xyz.domain
    10.17.148.148 serverxyzl07.xyz.domain
    10.17.148.149 serverxyzl08.xyz.domain

  10. Setup PCS clustering

    #install pre-req
    yum install -y pcs lvm2-cluster gfs2-utils fence-agents-scsi

    #Open firewall on old nodes
    for tcpport in 2224 3121 5403 21064; do     fwAddSrcIpPortProto 10.17.148.149 ${tcpport} tcp;   done;
    for udpport in 5404 5405; do     fwAddSrcIpPortProto 10.17.148.149 ${udpport} udp;   done;

    #Open firewall on new nodes
    for svr in `seq 141 144`; do   for tcpport in 2224 3121 5403 21064; do     fwAddSrcIpPortProto 10.17.148.${svr} ${tcpport} tcp;   done;   for udpport in 5404 5405; do     fwAddSrcIpPortProto 10.17.148.${svr} ${udpport} udp;   done; done;
    for svr in `seq 146 149`; do   for tcpport in 2224 3121 5403 21064; do     fwAddSrcIpPortProto 10.17.148.${svr} ${tcpport} tcp;   done;   for udpport in 5404 5405; do     fwAddSrcIpPortProto 10.17.148.${svr} ${udpport} udp;   done; done;


    #Apply changes
    firewall-cmd --reload;

    #Setup pubkey so all those nodes can ssh to each other
    cd .ssh/
    cat > id_rsa.pub << EOF
    <CHECK OTHER BOX FOR THIS KEY>
    EOF

    #Setup private key
    touch id_rsa;
    chmod 600 id_rsa;
    cat > id_rsa << EOF
    <CHECK OTHER BOX FOR THIS KEY>
    EOF

    cat id_rsa.pub >> authorized_keys;

    #change hacluster password
    passwd hacluster
    New Password: <KEY IN LASTPASS>
    Confirm Password: <KEY IN LASTPASS>

    #Enable cluster
    lvmconf --enable-cluster;

    #Create directory for iscsi mount
    mkdir -p /data/mvai-dev;

    # Enable pacemaker daemon
    systemctl enable pcsd;
    systemctl start pcsd;
    systemctl status pcsd;

    #DO THIS PART ON 01 NODE (e.g. serverxyzl01.xyz.domain)

    #Authenticate hacluster on new node
    pcs cluster auth serverxyzl07.xyz.domain

    #Add 1 new journal to /dev/mapper/vg_mvai--dev-lv_data_mvai--dev
    gfs2_jadd -j1 /dev/mapper/vg_mvai--dev-lv_data_mvai--dev

    #Update STONITH host list with new node
    pcs stonith update iscsi-stonith-device pcmk_host_list="serverxyzl01.xyz.domain serverxyzl02.xyz.domain serverxyzl03.xyz.domain serverxyzl04.xyz.domain serverxyzl05.xyz.domain serverxyzl06.xyz.domain serverxyzl07.xyz.domain"

    #Add the new node to the existing cluster
    pcs cluster node add serverxyzl07.xyz.domain


    #DO THIS PART ON NEW NODE:
    pcs cluster start
    pcs cluster enable

    #Add 'network.service' to the After variable in /etc/systemd/system/multi-user.target.wants/corosync.service
    systemctl daemon-reload;

    #Bounce the new node
    reboot

  11. SSH to Master node in Openshift and make the new node schedulable after it came up from rebooting

    oc adm manage-node serverxyzl07.xyz.domain --schedulable


Tags:

Post a Comment

Previous Post Next Post
